Specifications:
Model: ZQ02272*2
Color: black
Material: aluminum alloy+plastic
Input voltage: AC90-240V 50/60Hz
Rated power: 350W
Light source: OSRAM 7PCS 50W (RGBW) LEDs
Lighting angle: 4.5-45°
X-axis: 540°, X-axis fine-tuning 0-25516bit adjustable
Y-axis: 230°, Y-axis fine-tuning 0-255 16bit adjustable
Operation mode: self-propelled, sound-activated, master-slave, DMX
Control channel: 17CH
Protocol: standard DMX512 protocol, RDM protocol
Lamp output luminous flux: 10000lm
Illuminance: 25000Lux@5m
LED average life: 50000H
Strobe: 1-25Hz
Data connection: DMX three core XLR input/output
Display: LCD liquid crystal display
Protection grade: IP20
Working environment: -20℃-40℃
Product Features:
1. Super Beam Sense: Through optimized optical design, the beam aggregation is strong, the projected light is bright and sharp, bringing strong visual impact.
2. Superior performance: more precise control, smooth operation of the whole machine, low noise, increasing the convenience and efficiency of use.
3. Built-in Sound Control Mode: In this mode, the light beams and color changes of the fixtures will directly respond to changes in external sound, adding more interactivity and fun to performances, parties and other occasions.
4. Support DMX: Support DMX control to achieve synchronized control of multiple lighting effects to meet the needs of professional venues and increase the flexibility and convenience of use.
5. Widely used: Widely used in Disco, Dance Hall, Party, Bar Performance.
Installation and operating instructions：
1. Plugged into a grounded power outlet .
2. Install the equipment in a well-ventilated place at least 50cm from any surface, and ensure that the ventilation slots are not blocked.
3. Disconnect the equipment from the power supply before any operation.
4. The ambient temperature should not exceed 40°C, and the maximum ambient temperature is 45°C. Don't operate the device at higher temperatures.
5. The equipment should be stopped immediately, if a fault occurs, and do not repair the equipment by yourself. Improper maintenance can result in damage and malfunction. Contact technical support for repair approval. Only the same accessories can be used with the original parts, and make sure the power cord is not blocked or damaged.
6. Do not expose your eyes to light sources, which can be a sign of a seizure in sensitive people.
7. The lamps are only used for decoration and not suitable for ordinary household lighting.
8. Replacing the fuse: Unplug the device from the power supply, remove the fuse holder from its original position with a screwdriver, take out the burnt fuse, replace the fuse with the same characteristics, then re-rotate the screw, and connect the device to the power supply superior.
9. WARNING: Stop using it if the fuse is still blowing after being replaced. Please contact customer support for further instructions, continued use may cause serious damage.
10. Fix the equipment with the screw holes on the bracket to ensure that the equipment is firmly fixed to prevent vibration and movement during operation, and always check whether the structure of the equipment is strong enough to withstand equipment that is at least ten times.
11. The equipment must be fixed by professionals in places that elders and children cannot reach, and no one can pass under or over the pedestrian crossing.
12. End-of-life of the product: This sign indicates that this product should not be thrown into household waste in European Community countries and that waste should be recycled to support the sustainable recycling of resources in order to protect the environment and human health Utilize. If you need to recycle used electrical appliances, please go to an electrical appliance collection center or contact the dealer where you purchased the product to ensure the ecological recycling of the product.
13. Before cleaning the device, disconnect it from the power source if connected. Do not use harsh cleaners. Wipe off dust or dirt from the product with a clean cloth. We are not responsible for damage caused by incorrect handling, improper use or wear and tear.
14. We reserve the right to make technical modifications.
Packing List：
1. Beam light *2
2. Lock *4
3. Power cord *2
4. Instruction manual * 2
